HIKVISION DS-UAC-S1 Wireless Conference Speakerphone
Couldn't load pickup availability
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
 |
 |
Ask Our Experts Text Chat | Email |
|
Important Information Regarding Order and Pricing
|
Quality Certifications: |
Wireless Conference Speakerphone
- Adopts 8-mic array, picking up 360° clear sound with 5 meters range
- Adopts the HD speaker
- Supports steady and transient smart noise reduction, echo and squeal suppression, anti-reverberation to enhance speech quality and offer audio in high quality
- The built-in 7.2 V/3700 mAh lithium battery supports the device to last 10 hours after a full charge.
- Supports wireless connection through Bluetooth and a USB dongle
- Supports wired connection through a USB cable
- Driver-free design enables plug-and-play
- Compatible with leading online conferencing platform
Available models:
Product Data
- Microphone
- TypeMEMS
- Direction360° Omni-directional
- Pickup DistanceIn the radius up to 5 m
- Amount8
- Frequency Response100 Hz to 8 kHz
- Sensitivity-38 dBV/Pa
- SNR65 dB
- Sampling Rate16 kHz/32 kHz/48 kHz
- Special Function/AlgorithmBeam forming
- 3A AlgorithmAEC, ANS, AGC
- Speaker
- Rated Power3 W
- Maximum Output Loudness81 dBSPL @1 m, 1 kHz
- Speaker RangeIn the radius up to 8 m
- Effective Bandwidth (-10 dB)150 Hz to 15 kHz
- Total Harmonic Distortion (THD)<1% @ 1 kHz
- Functions
-
Audio Function
Supports steady noise reduction, such as the sound of air conditioner and fan, and transient noise reduction, such as the sound of falling, claps and steps.
Supports echo and squeal suppression, anti-reverberation to enhance speech quality and offer audio in high quality.
-
LED Indicator
Ambient light
Solid White: picking up sounds. Solid Red: mute. Green Light: speaker volume
Bluetooth light
Solid White: Only previously paired devices can connect to Bluetooth.
Flashing Blue: Unpaired devices can be paired with Bluetooth.
Solid Blue: The speakerphone connects to Bluetooth successfully.
Light remains off: Bluetooth is off.
Power light
Charging status: flashing white: charging; solid white: charging completed
Non-charging status: solid red: battery ≿15%; solid yellow: 15% < battery ≿30%; solid white: battery＿0%
- Communication
- Communication MethodBluetooth, USB Dongle, USB cable
- Wireless Communication Distance10 m
- Wired Communication DistanceCable length: 2 m
- Battery
- Capacity7.2 V/3700 mAh
-
Battery Life
10 hours when the volume is turned on to 75%.
The actual battery life depends on the usage environment and the battery health.
- Charging Temperature0 °C to 45 °C (32 °F to 113 °F)
- Quick Charge ProtocolPD 3.0 Protocol
- Discharging Temperature-20 ℿto 60 ℿ(-4 °F to 160 °F)
- Storage Temperature0 ℿto 35 ℿ(32 °F to 95 °F) (less than one year)
- Interface
- CableCable in package: type-C-to-C interface (with a type-C-to-A adapter on the cable)
- Device InterfaceUSB Type C
- Compatibility
-
System Requirement
Windows XP/7/8/10/11
Android 8.1 and above version
Linux 4.14 and above version
macOS 10.12 and above version
- General
- Power5 VDC ± 5%, max. 4.8 W
- Operating Condition-10 °C to 45 °C (14 °F to 113 °F). Humidity 90% or less (non-condensing)
- Dimension142.2 mm × 93.9 mm × 69.2 mm (5.60" × 3.70" × 2.72")
- Package Dimension273 mm × 140 mm × 82 mm (10.75" × 5.51" × 3.23")
- Approx. 645 g (1.42 lb.)
- With Package WeightApprox. 1190 g (2.62 lb.)
- ColorSilver gray
-
Packing List
Speakerphone × 1
USB Dongle × 1
USB 3.0 cable (2 m) × 1
Quick Start Guide × 1
Storage case box × 1
- TypeMEMS
- Direction360° Omni-directional
- Pickup DistanceIn the radius up to 5 m
- Amount8
- Frequency Response100 Hz to 8 kHz
- Sensitivity-38 dBV/Pa
- SNR65 dB
- Sampling Rate16 kHz/32 kHz/48 kHz
- Special Function/AlgorithmBeam forming
- 3A AlgorithmAEC, ANS, AGC
- Rated Power3 W
- Maximum Output Loudness81 dBSPL @1 m, 1 kHz
- Speaker RangeIn the radius up to 8 m
- Effective Bandwidth (-10 dB)150 Hz to 15 kHz
- Total Harmonic Distortion (THD)<1% @ 1 kHz
-
Audio Function
Supports steady noise reduction, such as the sound of air conditioner and fan, and transient noise reduction, such as the sound of falling, claps and steps.
Supports echo and squeal suppression, anti-reverberation to enhance speech quality and offer audio in high quality.
-
LED Indicator
Ambient light
Solid White: picking up sounds. Solid Red: mute. Green Light: speaker volume
Bluetooth light
Solid White: Only previously paired devices can connect to Bluetooth.
Flashing Blue: Unpaired devices can be paired with Bluetooth.
Solid Blue: The speakerphone connects to Bluetooth successfully.
Light remains off: Bluetooth is off.
Power light
Charging status: flashing white: charging; solid white: charging completed
Non-charging status: solid red: battery ≿15%; solid yellow: 15% < battery ≿30%; solid white: battery＿0%
- Communication MethodBluetooth, USB Dongle, USB cable
- Wireless Communication Distance10 m
- Wired Communication DistanceCable length: 2 m
- Capacity7.2 V/3700 mAh
-
Battery Life
10 hours when the volume is turned on to 75%.
The actual battery life depends on the usage environment and the battery health.
- Charging Temperature0 °C to 45 °C (32 °F to 113 °F)
- Quick Charge ProtocolPD 3.0 Protocol
- Discharging Temperature-20 ℿto 60 ℿ(-4 °F to 160 °F)
- Storage Temperature0 ℿto 35 ℿ(32 °F to 95 °F) (less than one year)
- CableCable in package: type-C-to-C interface (with a type-C-to-A adapter on the cable)
- Device InterfaceUSB Type C
-
System Requirement
Windows XP/7/8/10/11
Android 8.1 and above version
Linux 4.14 and above version
macOS 10.12 and above version
- Power5 VDC ± 5%, max. 4.8 W
- Operating Condition-10 °C to 45 °C (14 °F to 113 °F). Humidity 90% or less (non-condensing)
- Dimension142.2 mm × 93.9 mm × 69.2 mm (5.60" × 3.70" × 2.72")
- Package Dimension273 mm × 140 mm × 82 mm (10.75" × 5.51" × 3.23")
- Approx. 645 g (1.42 lb.)
- With Package WeightApprox. 1190 g (2.62 lb.)
- ColorSilver gray
-
Packing List
Speakerphone × 1
USB Dongle × 1
USB 3.0 cable (2 m) × 1
Quick Start Guide × 1
Storage case box × 1
