Home » HIKVISION DS-2TD3017T-3/V Thermographic Cube Camera
HIKVISION DS-2TD3017T-3/V
HIKVISION DS-2TD3017T-3/V
HIKVISION

HIKVISION DS-2TD3017T-3/V Thermographic Cube Camera

In stock
SKU: DS-2TD3017T-3/V
$1,644.00
Our standard leading time is estimated to be 40 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
Get More Information
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
Ask Our Experts
Text Chat | Email

Important Information Regarding Order and Pricing

  • The prices listed, such as $1000000 or $1,534,590.00, are placeholders and do not reflect the actual prices. These products on this page are typically specialized for project-specific requirements, and pricing depends on various factors such as the required quantity and any other project-specific requirements.
  • Please contact us to get the latest discount information (we can offer lower prices than all dealers).
  • Inventory Statement:Please note that the inventory status displayed for our products is not in real-time. We will inform you of the actual inventory status via email to ensure you have the most accurate information for your purchase decisions.
  • Minimum Order Amount Statement：For non-stock items, we have a minimum order value requirement of $3,000 USD. This threshold helps us to process your orders efficiently and provide you with the best possible service.
  • Please note that the prices mentioned are subject to the final Proforma Invoice (PI) prices, which will be provided to you after confirming your order. Additionally, the shipping costs for the products will be calculated separately and added to the total value of the order.
  • Final Price Explanation: Our prices include VAT and shipping charges. Please note that customs duties are not included.
  • If you have any further questions or need assistance, please don't hesitate to reach out. We are committed to providing you with the best price and service for your order.
  • We guarantee that the products we sell are official original products with the latest firmware versions. If you require the latest firmware for this product, please contact our customer service directly.
  • As authorized distributors, all orders and customs documents are provided by the original manufacturer. We also provide official technical support. For project-based orders, local warranty is provided by the manufacturer, while we provide warranty for dealer orders.
    If you have any other inquiries or need further clarification, please feel free to let us know. We are here to assist you.
Quality Certifications:



Thermographic Cube Camera

  • 160 × 120 (the resolution of output image is 640 × 480) resolution in thermal channel, high sensitivity sensor
  • Point, line and area for temperature measurement
  • Temperature range: -20°C to 150°C (-4°F to 302°F), 0 °C to 550 °C (32°F to 1022 °F); temperature accuracy: Max (±2 °C, ±2%)
  • Reliable temperature exception alarm function
  • 3D DNR, image detail enhancement
  • Audio alarm

  •

  •

  •

  •

  •

  •

Available models:

DS-2TD3017T-3/V


Product Data

  • Thermal
  • Max. Resolution256 × 192
  • Thermal Module
  • Image sensorVanadium Oxide Uncooled Focal Plane Arrays
  • Pixel Interval12 μm
  • NETDless than 40 mk (@25°C), F#=1.0
  • MRAD1.2 mrad
  • Field of View18° × 13.5° (H × V)
  • Min. Focusing Distance1.5 m
  • ApertureF 1.0
  • Lens (Focal Length)10 mm
  • Response waveband8 μm to 14 μm
  • Optical Module
  • Max. Resolution2688 × 1520
  • Image Sensor 1/2.7" Progressive Scan CMOS
  • Min. Illumination Color: 0.05 Lux @ (F1.6, AGC ON), B/W: 0.01 Lux @ (F1.6, AGC ON)
  • Field of View39.4° × 22.0°(H × V)
  • Aperture RangeF1.6
  • WDR120 dB
  • Shutter Speed1s to 1/100,000s
  • Day & NightIR cut filter with auto switch
  • Focal Length8 mm
  • Smart Function
  • VCA(Video Content Analysis)4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules.
  • Temperature Measurement3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line).
  • Temperature Range-20°C to 550°C (-4°F to 1,022°F)
  • Temperature AccuracyMax (± 2°C, ± 2%)
  • Infrared
  • IR Distanceup to 30m
  • IR Intensity and Angle Automatically adjusted
  • Network
  • Main Stream

    Thermal:

    25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240)

    Optical:

    50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

    60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)」

  • Sub stream

    Thermal:

    25 fps (704 × 576, 640 × 512, 320 × 240)

    Optical:

    50 Hz: 25 fps (704 × 576, 352 × 288)

    60 Hz: 30 fps (704 × 480, 352 × 240)

  • Video compressionH.265/H.264/MJPEG, H.265+/H.264+ encoding with Baseline/Main/High Profile
  • Audio compressionG.711u/G.711a/G.722.1/MP2L2/G.726/PCM
  • ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS,NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
  • Simultaneous live viewUp to 20
  • User/Host levelUp to 32 users, 3 levels: Administrator, Operator, User
  • Security measuresUser authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering
  • Integration
  • Alarm Input2-ch inputs (0 to 5 VDC)
  • Alarm Output2-ch relay outputs, alarm response actions configurable
  • Alarm ActionPreset/Patrol Scan/ Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage
  • Audio Input1 3.5mm Mic in/Line in interface. Line input: 2 to 2.4V[p-p], output impedance:1 KΩ ± 10%
  • Audio OutputLinear Level; Impedance: 600 Ω
  • Ethernet1 RJ45 10M/100M Self-adaptive Ethernet interface
  • SD Memory CardBuilt-in Micro SD card slot, support Micro SD/SDHC/SDXC card (up to 256G), support manual/alarm recording
  • Application ProgrammingSupport ISAPI, HIKVISION SDK and third-party management platform
  • ClientiVMS-4200
  • Web BrowserGoogle Chrome 57+, Mozilla Firefox 52+, Internet Explorer 10+, Mac Safari 12+
  • General
  • Menu LanguageEnglish
  • Power100 to 240 VAC, PoE (802.3af)
  • Power Consumption100 to 240 VAC, PoE (802.3af), max.8W
  • Work Temperature/Humidity-40°C to 60°C (-40°F to 140°F), 90% or less
  • Protection LevelIP68 Standard,TVS 6000V Lightning protection, surge protection, voltage transient protection
  • Dimensions286.7 mm × 175.2 mm × 150.1 mm (11.29″ × 6.9″ × 5.91″)
  • WeightApprox. 6.1 kg (13.45 lb)
  • Approval
  • EMC

    CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN50130-4: 2011+A1: 2014);

    RCM (AS/NZS CISPR 32: 2015);

    IC (ICES-003: Issue 7)

  • Safety

    CB: IEC 62368-1: 2014+A11;

    CE-LVD: EN 62368-1: 2014/A11: 2017;

    BIS: IS 13252 (Part 1): 2010/ IEC 60950-1: 2005

  • ProtectionIP68: IEC 60529-2013
  • Explosion-Proof Protection

    ATEX: II 2 G Ex db IIC T6 Gb/II 2 D Ex tb IIIC T80°C Db

    IECEx: Ex db IIC T6 Gb/ Ex tb IIIC T80°C Db

  • Anti-Corrosion ProtectionNEMA 4X (NEMA 250-2018), C5
