P4.8 outdoor rental LED display
- Excellent in precision, heat dissipation, toughness, and solidity with the die-casting aluminum cabinet design.
- 500 mm × 500 mm cabinet with multiple dot pitches available and both indoor and outdoor scenarios applicable.
- Front maintenance available with the magnetic suction design, and quick front maintenance and installation achievable with the fixed installation of module at any position.
- 10-seconds replacement achievable with power supply, display controller, and adapter board integrated.
- Fast locking from the top, bottom, left, and right; 2-seconds locking for adjacent cabinets; convenient wiring with aviation plugs.
- Pendant mounting and standing available for installation.
- Free of fans and noise with excellent heat dissipation.
- High refresh rate (up to 3840 Hz) and high grey scale.
Available models:
DS-D4448RO-CA
Product Data
- Cabinet
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP4.8
- Pixel Pitch4.8 mm
- Modules Component2 × 2
- Dimensions (W × H × D)500 mm × 500mm × 87 mm (19.69" × 19.69" × 3.43")
- Resolution104 × 104
- Area0.25 m?
- 8.5 Kg (18.74lb)
- Pixel Density42364 dots/m?
- Lamp Board Housingwith housing
- Cabinet MaterialDie-cast aluminum
- Maintenance MethodRear maintenance
- Cabinet Flatness0.2 mm
- Protection LevelIP54
- Display
- White Balance Brightness4500 cd/m?
- Color Temperature3000 K to 10000 K adjustable
- Viewing AngleHorizontal 160°, vertical 160°
- Contrast Ratio≿6000:1
- Color Uniformity≿± 0.003Cx,Cy
- Brightness Uniformity≿97_
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh Rate3840 Hz
- Grey Level16 bit
- Display Color281 trillion
- Power
- Power Supply110~220 VAC ± 15%
- Max. Consumption≿680 W/m?
- Average Consumption≿230 W/m?
- Working Environment
- Working Temperature-15-50 ℿ
- Working Humidity10%~85%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20~60 ℿ
- General
- Gross Weight85 Kg (187.4 lb)
- Package Dimension (W × H × D)560 mm × 580 mm × 670 mm (6 IN 1)
- LifespanLamp 100,000 hours
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP4.8
- Pixel Pitch4.8 mm
- Modules Component2 × 2
- Dimensions (W × H × D)500 mm × 500mm × 87 mm (19.69" × 19.69" × 3.43")
- Resolution104 × 104
- Area0.25 m?
- 8.5 Kg (18.74lb)
- Pixel Density42364 dots/m?
- Lamp Board Housingwith housing
- Cabinet MaterialDie-cast aluminum
- Maintenance MethodRear maintenance
- Cabinet Flatness0.2 mm
- Protection LevelIP54
- White Balance Brightness4500 cd/m?
- Color Temperature3000 K to 10000 K adjustable
- Viewing AngleHorizontal 160°, vertical 160°
- Contrast Ratio≿6000:1
- Color Uniformity≿± 0.003Cx,Cy
- Brightness Uniformity≿97_
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh Rate3840 Hz
- Grey Level16 bit
- Display Color281 trillion
- Power Supply110~220 VAC ± 15%
- Max. Consumption≿680 W/m?
- Average Consumption≿230 W/m?
- Working Temperature-15-50 ℿ
- Working Humidity10%~85%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20~60 ℿ
- Gross Weight85 Kg (187.4 lb)
- Package Dimension (W × H × D)560 mm × 580 mm × 670 mm (6 IN 1)
- LifespanLamp 100,000 hours
