HIKVISION DS-2CE16H8T-IT1F 5 MP Ultra Low Light Fixed Bullet Camera
Couldn't load pickup availability
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
Ask Our Experts Text Chat | Email |
Important Information Regarding Order and Pricing
|
Quality Certifications: |
5 MP Ultra Low Light Fixed Bullet Camera
- 5 MP high performance bullet camera
- Strong night performance, capturing images in ultra-low light down to 0.003 lux
- Clear imaging even against strong back lighting due to 130 dB true WDR technology
- 3D DNR technology delivers clean and sharp images
- EXIR 2.0: advanced infrared technology with 30 m IR distance
- Water and dust resistant (IP67)
- 4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)
Available models:
Product Data
- Camera
- Image Sensor5 megapixel progressive scan CMOS
- Max. Resolution2560 (H) × 1944 (V)
- Min. IlluminationColor: 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR
-
Shutter Time
PAL: 1/25 s to 1/50,000 s
NTSC: 1/30 s to 1/50,000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed lens
- Focal Length & FOV98° (2.8 mm), 78° (3.6 mm), 48° (6 mm)
- Lens MountM12
- Image
- Image SettingsBrightness, Sharpness, 3D DNR, Mirror, Smart IR
-
Frame Rate
TVI: 2 MP@25fps, 2 MP@30fps, 4 MP@25fps, 4 MP@30fps, 5 MP@20fps
AHD: 4 MP@25fps, 4 MP@30fps, 5 MP@20fps
CVI: 4 MP@25fps, 4 MP@30fps
CVBS: PAL, NTSC
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)≿130 dB
- Image EnhancementBLC
- Privacy Mask4 programmable privacy masks
- Noise ReductionLevel 1 to 9
- White BalanceAuto/Manual
- AGCYes
- Interface
- Video Output1 HD analog output, TVI/AHD/CVI/CVBS
- Event
- Motion Detection4 programmable areas
- General
- MaterialMetal
- Dimension81.9 mm × 86.7 mm × 217.9 mm (3.22" × 3.41" × 8.58" )
- Approx. 570 g (1.26 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing)
- CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
- LanguageEnglish
-
Power Supply
12 VDC ±25%
*You are recommended to use one power adapter to supply the power for one camera.
- ConsumptionMax. 5.8 W
- IR RangeUp to 30 m
- Approval
- ProtectionIP67
- Image Sensor5 megapixel progressive scan CMOS
- Max. Resolution2560 (H) × 1944 (V)
- Min. IlluminationColor: 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR
-
Shutter Time
PAL: 1/25 s to 1/50,000 s
NTSC: 1/30 s to 1/50,000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed lens
- Focal Length & FOV98° (2.8 mm), 78° (3.6 mm), 48° (6 mm)
- Lens MountM12
- Image SettingsBrightness, Sharpness, 3D DNR, Mirror, Smart IR
-
Frame Rate
TVI: 2 MP@25fps, 2 MP@30fps, 4 MP@25fps, 4 MP@30fps, 5 MP@20fps
AHD: 4 MP@25fps, 4 MP@30fps, 5 MP@20fps
CVI: 4 MP@25fps, 4 MP@30fps
CVBS: PAL, NTSC
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)≿130 dB
- Image EnhancementBLC
- Privacy Mask4 programmable privacy masks
- Noise ReductionLevel 1 to 9
- White BalanceAuto/Manual
- AGCYes
- Video Output1 HD analog output, TVI/AHD/CVI/CVBS
- Motion Detection4 programmable areas
- MaterialMetal
- Dimension81.9 mm × 86.7 mm × 217.9 mm (3.22" × 3.41" × 8.58" )
- Approx. 570 g (1.26 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing)
- CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
- LanguageEnglish
-
Power Supply
12 VDC ±25%
*You are recommended to use one power adapter to supply the power for one camera.
- ConsumptionMax. 5.8 W
- IR RangeUp to 30 m
- ProtectionIP67
