HIKVISION iDS-2CD7A47G0-XZHS(Y) 4MP ColorVu DeepinView Moto Varifocal Bullet Camera

Name: HIKVISION iDS-2CD7A47G0-XZHS(Y) 4MP ColorVu DeepinView Moto Varifocal Bullet Camera
Brand: HIKVISION
Price: 538.00 USD
Availability: InStock

In stock

SKU: iDS-2CD7A47G0-XZHS(Y)

$538.00

Our standard leading time is estimated to be 40 working days, even if it is shown as in stock, please confirm this lead time before purchasing.

Product variants

Get More Information
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.

Ask Our Experts

Text Chat | Email

Important Information Regarding Order and Pricing

The prices listed, such as $1000000 or $1,534,590.00, are placeholders and do not reflect the actual prices. These products on this page are typically specialized for project-specific requirements, and pricing depends on various factors such as the required quantity and any other project-specific requirements.
Please contact us to get the latest discount information (we can offer lower prices than all dealers).
Inventory Statement:Please note that the inventory status displayed for our products is not in real-time. We will inform you of the actual inventory status via email to ensure you have the most accurate information for your purchase decisions.
Minimum Order Amount Statement：For non-stock items, we have a minimum order value requirement of $3,000 USD. This threshold helps us to process your orders efficiently and provide you with the best possible service.
Please note that the prices mentioned are subject to the final Proforma Invoice (PI) prices, which will be provided to you after confirming your order. Additionally, the shipping costs for the products will be calculated separately and added to the total value of the order.
Final Price Explanation: Our prices include VAT and shipping charges. Please note that customs duties are not included.
If you have any further questions or need assistance, please don't hesitate to reach out. We are committed to providing you with the best price and service for your order.
We guarantee that the products we sell are official original products with the latest firmware versions. If you require the latest firmware for this product, please contact our customer service directly.
As authorized distributors, all orders and customs documents are provided by the original manufacturer. We also provide official technical support. For project-based orders, local warranty is provided by the manufacturer, while we provide warranty for dealer orders.

If you have any other inquiries or need further clarification, please feel free to let us know. We are here to assist you.

Quality Certifications:

4MP DarkfighterS DeepinView Moto Varifocal Bullet Camera

High quality imaging with 4 MP resolution
Excellent low-light performance via DarkfighterS technology
Clear imaging against strong back light due to 140 dB WDR technology
Efficient H.265+ compression technology to save bandwidth and storage
5 streams to meet a wide variety of applications
Water and dust resistant (IP67) and vandal proof (IK10)

Available models:

iDS-2CD7A47G0-XZHSY(2.8-12mm)

iDS-2CD7A47G0-XZHS(2.8-12mm)

Product Data

Camera
Image Sensor1/1.8" Progressive Scan CMOS
Max. Resolution2688 × 1520
Min. IlluminationColor: 0.0003 Lux @ (F1.0, AGC ON),B/W: 0.0001 Lux @ (F1.0, AGC ON),0 Lux with light
Shutter Time1 s to 1/100,000 s
Day & Night
IR cut filter,

Blue glass module (less ghost phenomenon)
Angle AdjustmentPan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360°

Lens
Focal Length & FOV2.8 to 12 mm, horizontal FOV 99.8° to 44.1°, vertical FOV 54.6° to 24.8°, diagonal FOV 113.8° to 51.1°
FocusAuto,Semi-auto,Manual
Iris TypeP-iris
ApertureF1.0 to F1.2

DORI
DORI
Wide: D: 63.4 m, O: 25.2 m, R: 12.7 m, I: 6.3 m

Tele: D: 140.7 m, O: 55.8 m, R: 28.1 m, I: 14.1 m

Illuminator
Supplement Light TypeHybrid (IR and White Light)
Supplement Light RangeUp to 50 m
Smart Supplement LightYes
IR Wavelength850 nm

AI Open Platform
Model SpecificationUp to 4 models, Model type: detection model, classification model, mixed model (detection model and classification model)

Video
Main Stream
50 Hz: 50 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)

60 Hz: 60 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480)

60 Hz: 30 fps (704 × 480, 640 × 480)
Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream
50 Hz: 25 fps (704 × 576, 640 × 480)

60 Hz: 30 fps (704 × 480, 640 × 480)
Fifth Stream
50 Hz: 25 fps (704 × 576, 640 × 480)

60 Hz: 30 fps (704 × 480, 640 × 480)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG,

Third stream: H.265/H.264,

Fourth stream: H.265/H.264/MJPEG,

Fifth stream: H.265/H.264/MJPEG
Video Bit Rate32 Kbps to 16 Mbps
H.264 TypeBaseline Profile,Main Profile,High Profile
H.265 TypeMain Profile
Bit Rate ControlCBR,VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Target CroppingYes
Region of Interest (ROI) 4 fixed regions for each stream

Audio
Audio TypeMono sound
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise FilteringYes

Network
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets
Simultaneous Live ViewUp to 20 channels
APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
User/Host
Up to 32 users

3 user levels: administrator, operator, and user
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3
Network Storage
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
ClientiVMS-4200,Hik-Connect
Web Browser
Plug-in required live view: IE 10, IE11,

Plug-in free live view: Chrome 57.0+, Firefox 52.0+

Image Parameters SwitchYes
Image SettingsSaturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser
Day/Night SwitchDay,Night,Auto,Schedule,Alarm Trigger,Video Trigger
Wide Dynamic Range (WDR)140 dB
Image EnhancementBLC,HLC,3D DNR,Defog, EIS
Privacy Mask8 programmable polygon privacy masks
Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.

Interface
Video Output1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
Ethernet Interface

1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB
Alarm 2 input(s), 2 output(s) (max. 24 VDC, 1 A)
Audio
1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,

1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset KeyYes
Power Output12 VDC, max. 100 mA

Event
Basic Event Motion detection,video tampering alarm,video quality diagnosis,exception (network disconnected, IP address conflict, illegal login, abnormal reboot, HDD full, HDD error), vibration detection
Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection, scene change detection,audio exception detection,defocus detection
LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning

Deep Learning Function
Multi-target-type Detection

Supports simultaneous detection and capture of human body, face and vehicle,

Gets 7 face features,

Gets 13 human body features,

Gets 2 vehicle features
Face Capture

Detects up to 60 faces simultaneously,

Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°,

Uploads face with background and closed-up face pictures
Face Comparison

Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total. ,

Supports face library encryption
People Counting
Supports crossline people counting,

Supports counting, displaying and exporting the people flow data of entering and exiting. (The data is stored in the flash.),

The real-time people flow data is displayed on the screen. ,

Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°.,

Uploads face with background and closed-up face picture.,

Supports real-time uploading and uploading by statistic cycle
Queue Management
Supports up to 8 detection regions, and independent arming schedule and linkage method,

Supports 2 detection modes: regional people queuing-up, waiting time detection,

Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue,

Supports raw data export for further analysis,

Supports real-time data uploading and scheduled data uploading,

Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold,

Waiting time detection: supports 1 alarm trigger condition, including greater than threshold
Heat Map
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area.,

Two report types are available, space heat map and time heat map line chart.
Hard Hat Detection
Detects up to 30 human targets simultaneously

Supports up to 4 shield regions
MetadataIntrusion detection,line crossing detection,region entrance detection,region exiting detection
Regional People Counting
Supports up to 8 detection regions, and independent arming schedule and linkage method,

Supports 3 detection modes: people density detection, number of people exception detection, waiting time exception detection

Supports parameter settings: alarm times per exception, alarm interval, first alarm delay,

Supports searching real-time number of people,

People density detection: supports scheduled uploading, number of people change uploading, congestion level uploading,

Number of people exception detection: supports 6 alarm trigger conditions, including greater than threshold A, less than threshold A, equal to threshold A, not equal to threshold A, greater than threshold A and less than threshold B, less than threshold A or greater than threshold B (threshold A should be less than threshold B),

Waiting time exception detection: supports 3 alarm trigger conditions, including greater than threshold A, less than threshold A, greater than threshold A and less than threshold B (threshold A should be less than threshold B)
On/Off Duty Detection
Supports up to 8 detection regions, and independent arming schedule and linkage method,

Supports 2 detection modes: absence detection, on/off duty detection,

Supports parameter settings: person on duty, absence duration

General
Power
Three-core terminal block,

12 VDC ± 20%, 1.90 A, max. 22.7 W,

24 VAC ± 20%, 1.39 A, max. 22.3 W,

PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.59 A to 0.44 A, max. 24.7 W
MaterialAluminum alloy body
Dimension

Ø140 mm × 378.4 mm (Ø5.5 × 14.9\")"
Package Dimension425 mm × 190 mm × 180 mm (16.7" × 7.5" × 7.1")
WeightApprox. 2280 g (5.0 lb.)
With Package WeightApprox. 3370 g (7.4 lb.)
Storage Conditions-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Language

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General FunctionHeartbeat,anti-banding,one-key reset,mirror,password protection,privacy mask, watermark, IP address filter, flash log, control timeout
HeaterYes
DemistYes

Approval
EMC
FCC: 47 CFR Part 15, Subpart B,

CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,

RCM: AS/NZS CISPR 32: 2015,

IC: ICES-003: Issue 7,

KC: KN32: 2015, KN35: 2015
Safety
UL: UL 62368-1,

CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017,

BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,

LOA: IEC/EN 60950-1
Environment
CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006
ProtectionIP67: IEC 60529-2013,IK10: IEC 62262:2002
Anti-Corrosion Protection-Y model: NEMA 4X (NEMA 250-2018)
Automotive and RailwayEN50121-4
OtherPVC FREE
