HIKVISION DS-2DE3A400BW-DE(T5) 3-inch 4 MP ColorVu Mini PT Dome Network Camera
Regular price
$195.99
Our standard leading time is estimated to be 40 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
Couldn't load pickup availability
Get More Information
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
 |
 |
Ask Our Experts Text Chat | Email |
|
Important Information Regarding Order and Pricing
|
Quality Certifications: |
3-inch 4 MP ColorVu Mini PT Dome Network Camera
- Focuses on human and vehicle targets classification based on deep learning
- Face capture: automatic selection of best shot; up to 5 faces detected and captured at the same time
- Linked audible and visual alarm. Built-in microphone and speaker
- Up to 2560 × 1440 @ 30 fps
- Min. illumination: Color: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light
- 24/7 colorful imaging with low power consumption. Up to 30 m white light distance
- 120 dB WDR, 3D DNR, HLC
- IP66; PoE
Available models:
DS-2DE3A400BW-DE(F1)(T5)
Product Data
- Camera
- Image Sensor1/1.8" progressive scan CMOS
- Min. IlluminationColor: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light
- Shutter Speed1/1 to 1/30,000 s
- Day & Night24/7 colorful imaging
- Zoom16x digital
- Max. Resolution2560 × 1440
- Lens
- Focal Length4 mm
-
FOV
Horizontal field of view: 88.7°
Vertical field of view: 46.5°
Diagonal field of view: 105.0°
- ApertureF1.0
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeWhite Light Distance: up to 30 m
- PTZ
- Movement Range (Pan)350°
- Movement Range (Tilt)0° to 90°
- Pan SpeedPan speed: configurable from 0.1° to 60°/s; preset speed: 60°/s
- Tilt SpeedTilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s
- Proportional PanYes
- Presets300
- Power-off MemoryYes
- Park ActionPreset, patrol scan
- 3D PositioningYes
- Preset FreezingYes
- Scheduled TaskPreset, patrol scan, dome reboot, dome adjust, aux output
- Video
-
Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
-
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
-
Third Stream
50Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
-
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)8 fixed regions for each stream
- Audio
- Audio CompressionG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM
- Environment Noise FilteringYes
- Network
- Network StorageNAS (NFS, SMB/ CIFS)
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
- APIISAPI, Hikvision SDK, Hik-Connect, Open Network Video Interface (Profile S, Profile G, Profile T), ISUP
- Simultaneous Live ViewUp to 20 channels
- User/HostUp to 32 users. 3 levels: Administrator, Operator and User
- SecurityAuthenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter
- Web BrowserIE 10+, Chrome 57+, Firefox 52+, Safari 12+
- Image
- Day/Night SwitchDay, night, auto, scheduled-switch
- Image EnhancementBLC, HLC, 3D DNR
- Wide Dynamic Range (WDR)120 dB WDR
- DefogDigital defog
- Regional ExposureYes
- Image SettingsSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
- Image Parameters SwitchYes
- Privacy MaskUp to 24 masks (8 masks for each scene)
- SNR＞52 dB
- Interface
- Built-in Speaker1 built-in speaker
- Power Output12 VDC; < 60 mA
- Ethernet Interface1 RJ45 10 M/100 M Ethernet interface; PoE (802.3at)
- On-board StorageBuilt-in memory card slot, support MicroSD/SDHC/SDXC, up to 512 GB
- Alarm1 input, 1 output
- Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
- RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
- ResetYes
- Event
- Basic EventVideo tampering alarm, motion detection, alarm input, alarm output, exception
- Smart EventLine crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, audio exception detection
- Alarm LinkagePreset, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, audible warning, white light flashing
- Deep Learning Function
- Face CaptureDetects up to 5 faces simultaneously. Supports detecting, capturing, grading, selecting of face in motion, and outputs the best face picture
-
Perimeter Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
- General
- General FunctionMirror, password protection, watermark, IP address filter
-
Power
12 VDC, 3.33 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A
Max. 14 W (including max. 4 W for white light)
- Operating ConditionHumidity: ≤ 90%, temperature: -30℃ to 65℃ (-22°F to 149°F)
- DemistYes
- Dimension179.3 mm × 120 mm × 182 mm (7.06" × 4.72" × 7.71")
- WeightApprox. 1.125 kg (2.48 lb.)
- Approval
- ProtectionIP66; 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection
