HIKVISION DS-7708NI-Q4 8-ch 1.5U 4K NVR
Regular price
¥52,500
Our standard leading time is estimated to be 40 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
Couldn't load pickup availability
Get More Information
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
Ask Our Experts Text Chat | Email |
Important Information Regarding Order and Pricing
|
Quality Certifications: |
8-ch 1.5U 4K NVR
- Up to 8 channel IP cameras can be connected
- Supports decoding H.265+/H.265/H.264+/H.264 video formats
- Up to 4K high-definition live view, storage and playback
- Up to 4-ch @ 1080p decoding capacity
- Up to 80 Mbps high incoming bandwidth ensures IP cameras can be connected
- 1 HDMI and 1 VGA interfaces: both interfaces support independent video output
- 4 HDDs for continuous video recording
Available models:
DS-7708NI-Q4
Product Data
- Video and Audio
- IP Video Input8-ch
- HDMI Output1-ch, 4K (3840 × 2160)/30Hz, ,1920 × 1080p/60Hz, ,1600 × 1200/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- VGA Output1-ch, 1920 × 1080/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- Incoming Bandwidth80 Mbps
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding
- Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
- Decoding Capability1-ch @ 8 MP (30 fps) / 4-ch @ 1080p (30 fps)
- Synchronous playback8-ch
- Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Network
- Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- PoE
- InterfaceN/A
- RAID
- RAID TypeNo
- Auxiliary Interface
- SATA4
- CapacityUp to 6 TB capacity for each disk
- Serial Interface1 RS-485 (half-duplex), 1 RS-232
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 2.0
- Alarm In/Out16/4 (16/8 optional)
- General
- Power Supply100 to 240 VAC,â‿80 W
- Consumptionâ‿15 W
- Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity10 % to 90 %
- Dimension (W × D × H)440 × 393 × 75 mm (17.3" × 15.5" × 3.0")
- â‿5 kg (11 lb)
- IP Video Input8-ch
- HDMI Output1-ch, 4K (3840 × 2160)/30Hz, ,1920 × 1080p/60Hz, ,1600 × 1200/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- VGA Output1-ch, 1920 × 1080/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
- Incoming Bandwidth80 Mbps
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
- Decoding Capability1-ch @ 8 MP (30 fps) / 4-ch @ 1080p (30 fps)
- Synchronous playback8-ch
- Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- InterfaceN/A
- RAID TypeNo
- SATA4
- CapacityUp to 6 TB capacity for each disk
- Serial Interface1 RS-485 (half-duplex), 1 RS-232
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 2.0
- Alarm In/Out16/4 (16/8 optional)
- Power Supply100 to 240 VAC,â‿80 W
- Consumptionâ‿15 W
- Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity10 % to 90 %
- Dimension (W × D × H)440 × 393 × 75 mm (17.3" × 15.5" × 3.0")
- â‿5 kg (11 lb)
