HIKVISION DS-2XM6365G0-IV(S)(M)(/ND) (C) Mobile Fisheye Network Camera
Regular price
$1,189.00
Our standard leading time is estimated to be 40 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
Couldn't load pickup availability
Get More Information
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
 |
 |
Ask Our Experts Text Chat | Email |
|
Important Information Regarding Order and Pricing
|
Quality Certifications: |
Mobile Fisheye Network Camera
- High quality imaging with 6 MP resolution
- Built-in microphone for real-time audio security
- Efficient H.265+ compression technology
- Clear imaging against strong back light due to digital WDR technology
- Smart features 6 abnormal detection, and 1 exception detections
- Up to 15 m IR range
Available models:
DS-2XM6365G0-IVS(1.27mm)(C)
DS-2XM6365G0-IVM/ND(1.27mm)(C)
DS-2XM6365G0-IVM(1.27mm)(C)
Product Data
- Camera
- Image Sensor1/2.8″ Progressive Scan CMOS
- Min. Illumination0.01 Lux @(F1.2, AGC ON), 0 Lux with IR
- Shutter Speed 1/3 s to 1/100,000 s
- Slow ShutterNo
- Wide Dynamic Range120 dB
- Day & NightIR Cut Filter
- Angle AdjustmentPan: 0° to 30°, tilt: 0° to 75°, rotate: 0° to 355°
- Lens
-
Focal Length & FOV
4 mm: horizontal FOV 77°, vertical FOV 42°, diagonal FOV 91°
6 mm: horizontal FOV 50°, vertical FOV 27°, diagonal FOV 59°
- Lens MountM12
- ApertureF1.6
- Video
- Max. Resolution1920 × 1080
-
Main Stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
-
Sub-Stream
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)
60Hz: 30fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)
- Third Streamno
-
Video Compression
Main Stream: H.265/H.264
Sub-Stream: H.265/H.264
- Video Bit Rate256 Kbps to 8 Mbps
- H.264 TypeBaseLine Profile/Main Profile/High Profile
- H.265 TypeMain Profile
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Audio
- Audio Compression G.711/G.726/AAC
- Audio Bit Rate64Kbps
- Audio Sampling Rate16 kHz
- Environment Noise FilteringYes
- Network
- ProtocolsTCP/IP, ICMP, HTTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, SNMP, QoS, FTP，SMTP，HTTPS
- Simultaneous Live ViewUp to 8 channels
- APIONVIF (PROFILE S, PROFILE G), ISAPI, SDK
- User/HostUp to 32 users,3 levels: Administrator, Operator and User
- Network StoragemicroSD/SDHC/SDXC card (up to 128 GB),
- ClientNo
- Web BrowserPlug-in required live view: IE10;
- Image
- Image SettingsSaturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
- Day/Night SwitchDay/Night/Auto/Schedule
- Image EnhancementBLC, 3D DNR,
- DNR 3D DNR
- Interface
-
Ethernet Interface
Without -M: 1 RJ45 10M/100M self-adaptive Ethernet port
-M: 1 four-core M12 aviation plug
- On-Board Storage Built-in micro SD/SDHC/SDXC slot, up to 128 GB
- Audio 1 built-in mic, mono sound
- Alarm No
- Reset KeyYes
- Event
- Basic Event Motion detection, video tampering alarm
- Smart EventNo
- LinkageUpload to FTP, notify monitoring center, send email, trigger recording
- General
-
Camera Dimension
Camera：99.3 × 96.7 × 52.8 mm (3.9″ × 3.8″ × 2.1″)
With package：252 × 160 × 95mm (9.9″ × 6.3″ × 3.7″)
-
Camera Weight
Camera: Approx. 430 g (0.9 lb.)
With package: 780 g (1.7 lb.)
- Startup and Operating Conditions -30 °C to 75 °C (-22 °F to 167°F), humidity less than 95% or less (non-condensing)
- General Function Anti-flicker, heartbeat, mirror,
-
Power Supply
-ID: 9-36V, ?5.5 mm coaxial power plug
-IM/ND: PoE (802.3af, 36 V to 57 V)
